Wang, N.; Babski, H.; Perdomo, J. E.; McMahan, S. B.; Ramakrishnan, A.; Biswas, T.; Bhandawat, V.

Movement of a limb is shaped by active forces generated by muscle contraction but also by passive forces within individual muscles and joints. In small animals such as insects, the contribution of passive forces to limb movement can match the active forces. However, most measurements of passive forces are limited to the femur-tibia joint in large insects. Here we take advantage of genetic tools in Drosophila to measure passive torques at multiple joints in the flys leg. We genetically inactivate all the motor neurons to assess passive forces. We find that the passive torques are well approximated by a linear spring, i.e., the passive torques linearly increase with angular deviation from the rest angle. The torques are much larger than the gravitational torque due to the leg itself. We estimate that the passive torques are seventy times smaller than necessary to support the weight of the animal. We also inactivated all the motor neurons in a freely standing fly and found that, as predicted from the model, the fly falls when the motor neurons are inactivated. We found that the height at which a fly stands, and, therefore the active forces vary. The flys height affects the time to initiate a fall. The time it takes for the fall is consistent with the active forces decaying with a time constant of ~100 ms. Thus, although passive forces are strong and will have a large effect on limb kinematics, they are not strong enough to support the weight of the fly.
